Technical data
| supply STR-422 230V | 230V AC |
| STR-422 24V | 24V AC/DC |
| current load AC-3 | <2A |
| control pulse current fL/N | <1mA |
| switch on time - programmable | 1sec÷10min |
| power supply indicator | LED green |
| signaling actuation | 2x LED red |
| power consumption | 1W |
| working temperature | -25÷50°C |
| connection | screw terminals 2,5mm² |
| dimensions | 1 module (18mm) |
| fixing | on rail TH-35 mm |
One-buttons roller blind controller
- Product Code: STR-422
